产品描述

GE微处理器板DS3800DMPC1F1E具有1个可编程定时器模块（TPM）。GE 微处理器板DS3800DMPC1E1C还装有 1 根 34 针带状电缆、1 根 50 针带状电缆和 3 个跳线。

GE微处理器板上的跳线DS3800DMPC1E1C具有以字母J为前缀的ID和数字。ID 为 J1、J2 和 J3。ID印在板上，与跳线相邻。使用跳线配置电路板。安装电路板的书面说明包括跳线的描述以及它们配置的处理段。每个跳线都有 2 个位置供您选择。一个位置是在引脚 1 和 2 上安装跳线。另一个位置是在引脚 2 和 3 上安装跳线。跳线是一个小塑料部件，安装在 2 个引脚上并连接 2 个引脚。信号在 2 个引脚之间传递，强制电路板处理所选配置中的信息。

34 针和 50 针带状电缆连接到电路板上，不设计为从电路板上卸下。34 针带状电缆端接在 34 针连接器中。50 针带状电缆端接在 50 针连接器中。它们的长度均为 5 英寸。它们设计用于在电路板安装在机架中时连接到与电路板相邻的连接器。将电缆上的接头按入驱动器中的接头，并确保其已完全连接。

GE DS3800DMPC1F1E 微处理器板 使用跳线配置电路板

Product description

The GE microprocessor board DS3800DMPC1F1E features a programmable timer module (TPM). The GE microprocessor board DS3800DMPC1E1C is also equipped with a 34-pin ribbon cable, a 50-pin ribbon cable, and three jumpers.

The jumper DS3800DMPC1E1C on the GE microprocessor board has an ID prefixed with the letter J and a number. The ids are J1, J2, and J3. The ID is printed on the board, adjacent to the jumper. Configure the board using jumpers. Written instructions for mounting the board include a description of the jumpers and the processing segments for which they are configured. Each jumper has 2 locations to choose from. One position is to install jumpers on pins 1 and 2. Another position is to install jumpers on pins 2 and 3. A jumper is a small plastic part that fits on 2 pins and connects 2 pins. The signal is passed between 2 pins, forcing the board to process the information in the selected configuration.

The 34 pin and 50 pin ribbon cables are attached to the circuit board and are not designed to be removed from the board. The 34-pin ribbon cable ends in a 34-pin connector. The 50-pin ribbon cable ends in a 50-pin connector. They are all 5 inches in length. They are designed to connect to connectors adjacent to the board while it is mounted in a rack. Press the connector on the cable into the connector in the driver and make sure it is fully connected.
