GE DS3800DPLA1B1A Mark IV的涡轮系列的一部分

GE DS3800DPLA1B1A Mark IV的涡轮系列的一部分

产品描述

该DS3800DPLA1B1A是通用电气（GE）名为Speedtronic Mark IV的涡轮系列的一部分。DS3800DPLA1B1A板包含一个小型电位计，也称为可变电阻器。该可变电阻器在蓝色方块的侧面有一个可调节的螺钉。通过调整螺钉，操作员可以控制通过电路板的能量。该板还包含 LED。

有三个红色 LED，当能量在电路板周围移动时亮起.该板包括七个电阻器。四个连接到板上，颜色为蓝色，另外三个连接到终端塔。每个电阻器都有单独的色带，用于标识每个电阻器能够处理的欧姆数。该板共有六个终端塔。这些凸起的塔具有金色，顶部包括一个平顶螺钉。这些塔允许根据需要有效地互换电阻器、二极管和电容器。

终端塔目前还连接了一个淡黄色的聚丙烯电容器。DS3800DPLA1B1A还有大约二十个单独的金属桩。这些桩称为跳线端口。跳线端口可以在一个盖子下覆盖两个木桩，以各种方式相应地引导能量流。DS3800DPLA1B1A带有七个蓝色盖，可用于跳线端口。该板旨在连接到更大的板以正常工作。较大的电路板有时可能被称为“主板”。因此，DS3800DPLA1B1A被认为是“子板”。为了连接到“主板”，DS3800DPLA1B1A具有带连接器的带状线束。为了使DS3800DPLA1B1A在“主板”上稳定，还有四个端口用于放置塑料锚。

GE DS3800DPLA1B1A Mark IV的涡轮系列的一部分

Product description

The DS3800DPLA1B1A is part of a General Electric (GE) family of turbines called the Speedtronic Mark IV. The DS3800DPLA1B1A board contains a small potentiometer, also known as a variable resistor. The variable resistor has an adjustable screw on the side of the blue square. By adjusting the screws, the operator can control the amount of energy passing through the board. The board also contains leds.

There are three red leds that light up as energy moves around the board. The board consists of seven resistors. Four are connected to the board, colored blue, and the other three are connected to the terminal tower. Each resistor has a separate ribbon that identifies the number of ohms each resistor is capable of handling. The board has a total of six terminal towers. These raised towers have a gold color and include a flat-top screw at the top. These towers allow the efficient exchange of resistors, diodes and capacitors as needed.

The terminal tower is also currently connected to a pale yellow polypropylene capacitor. DS3800DPLA1B1A also has about twenty individual metal posts. These posts are called jumper ports. The jumper port can cover two stakes under a cover, directing the energy flow accordingly in various ways. The DS3800DPLA1B1A comes with seven blue covers that can be used for jumper ports. The board is designed to be attached to a larger board to function properly. Larger circuit boards may sometimes be referred to as "motherboards". Therefore, DS3800DPLA1B1A is considered a "daughter board". For connection to the "motherboard", the DS3800DPLA1B1A has a ribbon harness with connectors. In order to stabilize the DS3800DPLA1B1A on the "motherboard", there are also four ports for placing plastic anchors.
