IS200EMCSG1A GE 励磁机多桥传导传感器

 IS200EMCSG1A GE 励磁机多桥传导传感器

产品描述

IS200EMCSG1A型号是通用电气生产的EX2100创新系列的一部分。该模块是一个激励器多桥传导传感器控制。

该板共有四个内置于电路板中的传导传感器，它们位于电路板的底部边缘，标记为 E1、E2、E3 和 E4。在传感器E2和E3之间有两个独立的传感器电路，标记为U1和U2。

IS200EMCSG1A板的另一个特点是两个六插头连接器，允许电源。这些连接器位于电路板的另一侧，与传导传感器相邻，最靠近电路板的字母数字目录号。该板上还有四个金属膜电阻器和一个单独的陶瓷电容器。由于其尺寸，该板的元件很少，但通常可以配置为在高电流下运行。

 IS200EMCSG1A GE 励磁机多桥传导传感器

Product description

The IS200EMCSG1A model is part of the EX2100 innovation family produced by General Electric. The module is a driver multi-bridge conduction sensor control.

The board has a total of four conduction sensors built into the board, which are located on the bottom edge of the board and labeled E1, E2, E3, and E4. There are two separate sensor circuits between sensor E2 and E3, labeled U1 and U2.

Another feature of the IS200EMCSG1A board is the two six-plug connectors that allow power supply. These connectors are located on the other side of the board, adjacent to the conduction sensor, closest to the board's alphanumeric catalog number. There are also four metal film resistors and a separate ceramic capacitor on the board. Due to its size, the board has few components, but can usually be configured to operate at high current.

 IS200EMCSG1A GE 励磁机多桥传导传感器
